Line Modules Booksize
3.8 Smart Line Modules (5 kW und 10 kW) with external air cooling
Booksize power units
312 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Internal air cooling 6SL3131– 6AE15–0AAx 6AE21–0AAx
Rated power kW 5 10
Circuit-breaker type designation
(status 07/2007 and later)
Rated current
Short-circuit current rating SCCR at 400 V
AC
A
kA
3RV1042-4BA10
14 ... 20
100
3RV1042-4FA10
28 ... 40
100
Circuit-breaker type designation
UL489/CSA C22.2 No. 5-02
Rated current
Rated short circuit current SCCR
A
kA
To be added To be added
UL safety fuse type AJT Class J
Rated current
Short-circuit current rating SCCR at 600 V
AC
A
kA
AJT16
16
200
AJT35
35
200
Safety fuses NH
Rated current A
3NA3 805
16
3NA3 814
35
Sound pressure level dB(A) < 60 < 60
Cooling air requirement m
3
/h 29.6 29.6
Rated voltage for rated data 380 V 3 AC
Weight kg 5.3 5.4
1)
The specified values apply to 380 V
2)
For an overview, see the power loss tables in Cabinet Design chapter.
