Line Connection Booksize
2.2 Overview: line filters
Booksize power units
38 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Basic Line Filter for Smart Line Modules
Basic Line Filters for Smart Line Modules are specified for total cable lengths of up to 150
m (shielded) of category C2 to EN 61800-3. Basic Line Filters 16 kW and 36 kW for Smart
Line Modules are specified for total cable lengths of up to 350 m (shielded) of category C2
to EN 61800-3.
Note
The acceptance of machines with EPCOS components has to be charged for.
Table 2-1 Overview
Order No.
Basic Line Filter for Active Line Modules with line reactor
16 kW 6SL3000-0BE21-6DAx
36 kW 6SL3000-0BE23-6DAx
55 kW 6SL3000-0BE25-5DAx
Basic Line Filter for Active Line Modules with Active Interface Modules
55 kW 6SL3000-0BE25-5DAx
80 kW 6SL3000-0BE28-0DAx
120 kW 6SL3000-0BE31-2DAx
Wideband Line Filter for Active Line Modules
16 kW 3SL3000-0BE21-6AAx
36 kW 3SL3000-0BE23-6AAx
55 kW 3SL3000-0BE25-5AAx
80 kW 3SL3000-0BE28-0AAx
120 kW 3SL3000-0BE31-2AAx
Basic Line Filter for Basic Line Modules
20 kW 6SL3000-0BE21-6DAx
40 kW 6SL3000-0BE23-6DA1
100 kW 6SL3000-0BE31-2DAx
Basic Line Filter for Smart Line Modules
5 kW 6SL3000-0HE15-0AAx
10 kW 6SL3000-0HE21-0AAx
16 kW 6SL3000-0BE21-6DAx
36 kW 6SL3000-0BE23-6DAx
