Cabinet Design and EMC Booksize
9.2 Selecting devices required to operate SINAMICS
Booksize power units
498 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Table 9-2 Requirements regarding line fuses and circuit-breakers for Active Line Modules
16 kW 36 kW 55 kW 80 kW 120 KW
I
rated
fuse 35 A 80 A 125 A 160A 250A
I
fuse
0.2 s >180 A >360 A >450 A >650 A >865 A
I
fuse
4 s >130 A >260 A >350 A >505 A >675 A
I
fuse
10 s >100 A >200 A >250 A >360 A >480 A
I
fuse
240 s >60 A >135 A >200 A >280 A >380 A
Table 9-3 Requirements regarding line fuses and circuit-breakers for Smart Line Modules
5 kW 10 kW 16 kW 36 kW
I
rated
fuse 16 A 35 A 35 A 80 A
I
fuse
0.2 s >70 A >100 A >180 A >360 A
I
fuse
4 s >50 A >80 A >130 A >260 A
I
fuse
10 s >42 A >65 A >100 A >200 A
I
fuse
240 s >30 A >45 A >60 A >135 A
See catalog D21.1
Table 9-4 Requirements regarding line fuses and circuit-breakers for the Basic Line Modules
20 kW 40 kW 100 kW
I
rated
fuse 50 A 80 A 200 A
I
fuse
0.2 s >260 A >360 A >800 A
I
fuse
4 s >190 A >260 A >600 A
I
fuse
10 s >145 A >200 A >400 A
I
fuse
240 s >90 A >135 A >310 A
