9.7 Cooling
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
547
Electronic losses of Motor Modules/Line Modules
Table 9-24 Electronic losses of Motor Modules/Line Modules
Component Internal/external air cooling
Power dissipation [W]
3 A 20.4
5 A 20.4
9 A 20.4
18 A 20.4
30 A 21.6
45 A 28.8
60 A 28.8
85 A 36.0
132 A 36.0
Single Motor Modules
200 A 36.0
3 A 18.0
5 A 18.0
9 A 18.0
Single Motor Modules
Booksize Compact
18 A 18.0
3 A 24.0
5 A 24.0
9 A 24.0
Double Motor Modules
18 A 24.0
1.7 A 24.0
3 A 24.0
Double Motor Modules
Booksize Compact
5 A 24.0
16 kW 26.4
36 kW 36.0
55 kW 45.6
80 kW 36.0
Active Line Modules
120 kW 60.0
20 kW 144
40 kW 283.6
Basic Line Modules
100 kW 628
5 kW 24.0
10 kW 31.2
16 kW 26.4
Smart Line Module
36 kW 36.0
Smart Line Module
Booksize Compact
16 kW 26.4
