Siemens SINUMERIK 802D sl Instruction Manual

A.1 List of machine data
Machine and Setting Data 802D
A-208
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
20380 TOOL_CORR_MODE_G43G44
– Handling of tool length compensation G43/44 RESET
C01, C08, C11 – BYTE
Default – 0 0 2 2/2
20450 LOOKAH_RELIEVE_BLOCK_CYCLE
– Block cycle time relief factor POWER ON
EXP, C05 – DOUBLE
Default – 0.0 – – 2/2
20460 LOOKAH_SMOOTH_FACTOR
% Smoothing factor for Look Ahead NEW CONF
EXP, C05 – DOUBLE
Default – 0.0 0. 500.0 2/2
20500 CONST_VELO_MIN_TIME
s Minimum time with constant velocity POWER ON
EXP, C05 – DOUBLE
Default – 0.0 0.0 0.1 2/2
20550 EXACT_POS_MODE
– Exact stop conditions with G00 and G01 NEW CONF
EXP – BYTE
Default – 0 0 33 2/2
20552 EXACT_POS_MODE_G0_TO_G1
– Exact stop conditions with the transition G00–>G01 NEW CONF
EXP – BYTE
Default – 0 0 5 2/2
20700 REFP_NC_START_LOCK
– NC start disable without reference point RESET
C01, C03 – BOOLEAN
Default – TRUE – – 2/2
20730 G0_LINEAR_MODE
– Interpolation behavior with G0 POWER ON
C09 – BOOLEAN
Default – TRUE – – 2/2
20732 EXTERN_G0_LINEAR_MODE
– Interpolation behavior with G00 POWER ON
N12 – BOOLEAN
Default – TRUE – – 2/2
20734 EXTERN_FUNCTION_MASK
– Function mask for external language RESET
N12 – DWORD
Default – 0 0 0xFFFF 2/2
21000 CIRCLE_ERROR_CONST
mm Circle end point monitoring constant POWER ON
C06 – DOUBLE
Default – 0.01 – – 2/2
21010 CIRCLE_ERROR_FACTOR
– Circle end point monitoring factor POWER ON
C06 – DOUBLE
Default – 0.001 – – 2/2
21020 WORKAREA_WITH_TOOL_RADIUS
– Tool radius with working area limitation RESET
C03, C06 – BOOLEAN
Default – FALSE – – 2/2
