Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-209
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
22000 AUXFU_ASSIGN_GROUP
– Auxiliary function group POWER ON
C04 – BYTE
Default 255 1 1 64 7/2
plus 64 – – – 2/2
22010 AUXFU_ASSIGN_TYPE
– Auxiliary function type POWER ON
C04 – STRING
Default 255 ”” – – 7/2
plus 64 – – – 2/2
22020 AUXFU_ASSIGN_EXTENSION
– Auxiliary function extension POWER ON
C04 – BYTE
Default 255 0 0 99 7/2
plus 64 – – – 2/2
22030 AUXFU_ASSIGN_VALUE
– Auxiliary function value POWER ON
C04 – DWORD
Default 255 0 – – 7/2
plus 64 – – – 2/2
22035 AUXFU_ASSIGN_SPEC
– Output specification POWER ON
C04 – DWORD
Default 255 0 – – 7/2
plus 64 – – – 2/2
22040 AUXFU_PREDEF_GROUP
– Predefined auxiliary function groups POWER ON
C04 – BYTE
Default 33 1, 1, 1, 1, 1, 1, 2, 2, 2, 2, 2,
4, 4, 4, 4, 4, 4, 3, 1, 1, 1, ...
0 64 7/2
plus – – – – 2/2
22050 AUXFU_PREDEF_TYPE
– Predefined auxiliary function type POWER ON
C04 – STRING
Default 33 “M”, “M”, “M”, “M”, “M”, “M”,
“M”, “M”, “M”, “M”, “M”, “M”,
“M”...
– – 7/2
plus – – – – 2/2
22060 AUXFU_PREDEF_EXTENSION
– Predefined auxiliary function extension POWER ON
C04 – BYTE
Default 33 0, 0, 0, 0, 0, 1, 1, 1, 1, 1,
1, 1, 1, 1, 1, 1, 1, 1, 0, 0,
0…
0 99 7/2
plus – – – – 2/2
22070 AUXFU_PREDEF_VALUE
– Predefined auxiliary function value POWER ON
C04 – DWORD
Default 33 0, 1, 2, 17, 30, 6, 3, 4, 5,
19, 70, 40, 41, 42, 43, 44,
45, –1...
– – 7/2
plus – – – – 2/2
22254 AUXFU_ASSOC_M0_VALUE
– Additional M functions for program stop POWER ON
C01, C03, C10 – DWORD
Default – –1 – – 2/2
