Machine and Setting Data 802D
A.1 List of machine data
A-219
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
34010 REFP_CAM_DIR_IS_MINUS
– Reference point approach in the negative direction RESET
–, – – BOOLEAN
Default – FALSE – – 2/2
34020 REFP_VELO_SEARCH_CAM
mm/min,
rev/min
Cam approach velocity RESET
–, –, – – DOUBLE
Default – 5000.00 – – 2/2
34030 REFP_MAX_CAM_DIST
mm,
degrees
Max. distance to reference cam RESET
–, – – DOUBLE
Default – 10000.0 – – 2/2
34040 REFP_VELO_SEARCH_MARKER
mm/min,
rev/min
Velocity when searching for the reference mark RESET
–, –, – – DOUBLE
Default 1 300.00 – – 2/2
34050 REFP_SEARCH_MARKER_REVERSE
– Direction reversal on reference cam RESET
–, – – BOOLEAN
Default 1 FALSE – – 2/2
34060 REFP_MAX_MARKER_DIST
mm,
degrees
Max. distance to reference mark RESET
–, – – DOUBLE
Default 1 20.0 – – 2/2
34070 REFP_VELO_POS
mm/min,
rev/min
Reference point approach velocity RESET
–, –, – – DOUBLE
Default – 10000.00 – – 7/2
plus – 1000.00 – – 2/2
34080 REFP_MOVE_DIST
mm,
degrees
Reference point distance NEW CONF
–, – – DOUBLE
Default 1 –2.0 – – 2/2
34090 REFP_MOVE_DIST_CORR
mm,
degrees
Reference point offset NEW CONF
–, –, –, – – DOUBLE
Default 1 0.0 – – 2/2
34100 REFP_SET_POS
mm,
degrees
Reference point position RESET
–, – – DOUBLE
Default 4 0.0, 0.0, 0.0, 0.0 –45000000 45000000 2/2
