Siemens SINUMERIK 802D sl Instruction Manual

A.1 List of machine data
Machine and Setting Data 802D
A-220
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
34110 REFP_CYCLE_NR
– Order of axes when referencing POWER ON
– – DWORD
Default – 1, 2, 3, 4, 5, 6, 7, 8, 9, 10,
11, 12, 13, 14, 15, 16, 17,
18, 19, 20, 21, 22, 23, 24,
25, 26, 27, 28, 29, 30, 31,
32, 33, 34, 35, 36, 37, 38,
39, 40, 41, 42, 43, 44, 45,
46, 47, 48, 49, 50, 51, 52,
53, 54, 55, 56, 57, 58, 59,
60, 61, 62, 63, 64
–1 31 7/2
plus – 1 – – 2/2
34120 REFP_BERO_LOW_ACTIVE
– Polarity change of the BERO cam POWER ON
– – BOOLEAN
Default – FALSE – – 2/2
34200 ENC_REFP_MODE
– Referencing mode POWER ON
–, – – BYTE
Default 1 1 0 8 2/2
34210 ENC_REFP_STATE
– Absolute encoder adjusting status IMMED.
–, –, – – BYTE
Default 1 0 0 2 2/2
34220 ENC_ABS_TURNS_MODULO
– Modulo range of the rotary absolute encoder POWER ON
–, – – DWORD
Default 1 4096 1 100000 2/2
34990 ENC_ACTVAL_SMOOTH_TIME
s Smoothing time constant for actual values RESET
– – DOUBLE
Default 1 0.0 0.0 0.5 3/3
35000 SPIND_ASSIGN_TO_MACHAX
– Assignment ‘spindle – machine axis’ POWER ON
–, –, – – BYTE
Default – 0 0 2/2
35010 GEAR_STEP_CHANGE_ENABLE
– Gear stage change possible RESET
–, – CTEQ DWORD
Default – 0 0 12 2/2
35012 GEAR_STEP_CHANGE_POSITION
mm,
degrees
Gear stage change position NEW CONF
–, – CTEQ DOUBLE
Default 6 0.0, 0.0, 0.0, 0.0, 0.0, 0.0 – – 2/2
35014 GEAR_STEP_USED_IN_AXISMODE
– Gear stage for axis mode with M70 NEW CONF
–, –, – CTEQ DWORD
Default – 0 0 5 2/2
35020 SPIND_DEFAULT_MODE
– Spindle park position RESET
–, – CTEQ BYTE
Default – 0 0 3 2/2
