Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-221
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
35030 SPIND_DEFAULT_ACT_MASK
– Activate spindle park position RESET
–, – CTEQ BYTE
Default – 0x00 0 0x03 2/2
35040 SPIND_ACTIVE_AFTER_RESET
– Own spindle RESET POWER ON
–, – CTEQ BYTE
Default – 0 0 2 2/2
35100 SPIND_VELO_LIMIT
rev/min Maximum spindle speed POWER ON
–, –, – CTEQ DOUBLE
Default – 10000.0 1.0e–3 – 7/2
35110 GEAR_STEP_MAX_VELO
rev/min Maximum speed for gear stage change NEW CONF
–, –, – CTEQ DOUBLE
Default 6 500.0, 500.0, 1000.0,
2000.0, 4000.0, 8000.0
– – 2/2
35120 GEAR_STEP_MIN_VELO
rev/min Minimum speed for gear stage change NEW CONF
–, –, – CTEQ DOUBLE
Default 6 50.0, 50.0, 400.0, 800.0,
1500.0, 3000.0
– – 2/2
35130 GEAR_STEP_MAX_VELO_LIMIT
rev/min Maximum speed of gear stage NEW CONF
–, –, – CTEQ DOUBLE
Default 6 500.0, 500.0, 1000.0,
2000.0, 4000.0, 8000.0
1.0e–3 – 2/2
35140 GEAR_STEP_MIN_VELO_LIMIT
rev/min Minimum speed of gear stage NEW CONF
–, –, – CTEQ DOUBLE
Default 6 5.0, 5.0, 10.0, 20.0, 40.0,
80.0
– – 2/2
35150 SPIND_DES_VELO_TOL
– Spindle speed tolerance RESET
–, –, –, –, – – DOUBLE
Default – 0.1 0.0 1.0 2/2
35160 SPIND_EXTERN_VELO_LIMIT
rev/min Spindle speed limitation from PLC NEW CONF
–, – CTEQ DOUBLE
Default – 1000.0 1.0e–3 – 2/2
35200 GEAR_STEP_SPEEDCTRL_ACCEL
rev/s@ Acceleration in the control mode NEW CONF
–, –, – CTEQ DOUBLE
Default 6 30.0, 30.0, 25.0, 20.0,
15.0, 10.0
1.0e–3 – 2/2
35210 GEAR_STEP_POSCTRL_ACCEL
rev/s@ Acceleration in the position–controlled mode NEW CONF
–, –, – CTEQ DOUBLE
Default 6 30.0, 30.0, 25.0, 20.0,
15.0, 10.0
1.0e–3 – 2/2
35300 SPIND_POSCTRL_VELO
rev/min Position controller starting speed NEW CONF
–, – CTEQ DOUBLE
Default – 500.0 – – 2/2
