Siemens SINUMERIK 802D sl Instruction Manual

A.1 List of machine data
Machine and Setting Data 802D
A-222
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
35310 SPIND_POSIT_DELAY_TIME
s Positioning delay time NEW CONF
–, – CTEQ DOUBLE
Default 6 0.0, 0.05, 0.1, 0.2, 0.4, 0.8 – – 2/2
35350 SPIND_POSITIONING_DIR
– Direction of rotation when positioning RESET
– CTEQ BYTE
Default – 3 3 4 2/2
35400 SPIND_OSCILL_DES_VELO
rev/min Reciprocating speed NEW CONF
–, – CTEQ DOUBLE
Default – 500.0 – – 2/2
35410 SPIND_OSCILL_ACCEL
rev/s@ Acceleration when reciprocating NEW CONF
–, – CTEQ DOUBLE
Default – 16.0 1.0e–3 – 2/2
35430 SPIND_OSCILL_START_DIR
– Starting direction when reciprocating RESET
– CTEQ BYTE
Default – 0 0 4 2/2
35440 SPIND_OSCILL_TIME_CW
s Reciprocation time for M3 direction NEW CONF
– CTEQ DOUBLE
Default – 1.0 – – 2/2
35450 SPIND_OSCILL_TIME_CCW
s Reciprocation time for M4 direction NEW CONF
– CTEQ DOUBLE
Default – 0.5 – – 2/2
35500 SPIND_ON_SPEED_AT_IPO_START
– Feed enable with spindle in setpoint range RESET
–, –, – CTEQ BYTE
Default – 1 0 2 2/2
35510 SPIND_STOPPED_AT_IPO_START
– Feed enable with the spindle stopped RESET
–, –, – CTEQ BOOLEAN
Default – FALSE – – 2/2
35550 DRILL_VELO_LIMIT
rev/min Maximum speeds for tapping NEW CONF
–, –, – CTEQ DOUBLE
Default 6 10000.0, 10000.0,
10000.0, 10000.0,
10000.0, 10000.0
1 – 2/2
36000 STOP_LIMIT_COARSE
mm,
degrees
Exact stop coarse NEW CONF
– – DOUBLE
Default – 0.04 – – 2/2
36010 STOP_LIMIT_FINE
mm,
degrees
Exact stop fine NEW CONF
– – DOUBLE
Default – 0.01 – – 2/2
