Siemens SINUMERIK 802D sl Instruction Manual

A.1 List of machine data
Machine and Setting Data 802D
A-224
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
36302 ENC_FREQ_LIMIT_LOW
% Encoder limit frequency resynchronization NEW CONF
EXP, –, –, – – DOUBLE
Default 1 99.9, 99.9 0 100 2/2
36310 ENC_ZERO_MONITORING
– Zero mark monitoring NEW CONF
EXP, –, – – DWORD
Default 1 0, 0 – – 2/2
36400 CONTOUR_TOL
mm,
degrees
Contour monitoring tolerance band NEW CONF
–, – – DOUBLE
Default – 1.0 – – 2/2
36500 ENC_CHANGE_TOL
mm,
degrees
Position actual–value switching tolerance NEW CONF
–, – – DOUBLE
Default – 0.1 – – 2/2
36600 BRAKE_MODE_CHOICE
– Brake behavior at hardware limit switch POWER ON
EXP, – CTEQ BYTE
Default – 1 0 1 7/2
plus – 0 – – 2/2
36610 AX_EMERGENCY_STOP_TIME
s Time of braking ramp in case of errors NEW CONF
– – DOUBLE
Default – 0.05 – – 2/2
36620 SERVO_DISABLE_DELAY_TIME
s Cutout delay controller enable NEW CONF
– – DOUBLE
Default – 0.1 – – 2/2
36710 DRIFT_LIMIT
% Limit value for automatic drift compensation NEW CONF
EXP, –, – – DOUBLE
Default 1 0.0 0 1.e9 1/1
plus – 1.0 – 5 3/3
36720 DRIFT_VALUE
% Drift base value NEW CONF
EXP, –, – – DOUBLE
Default 1 0.0 – – 2/2
37000 FIXED_STOP_MODE
– Mode “Traversing to fixed stop” POWER ON
– CTEQ BYTE
Default – 0 0 3 2/2
37002 FIXED_STOP_CONTROL
– Sequence control when traveling to fixed stop POWER ON
– – BYTE
Default – 0 0 3 2/2
37010 FIXED_STOP_TORQUE_DEF
% Fixed stop clamping torque default setting POWER ON
– CTEQ DOUBLE
Default – 5.0 0.0 100.0 2/2
