Siemens SINUMERIK 802D sl Instruction Manual

5.3 Dimension drawings and drilling patterns for the NC full keyboard
Dimension Drawings
5-46
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Dimension drawing for the NC full keyboard (installed beneath the PCU)
0
309.4
302.2
0
7.2
154.7
145
0
87.5
24
2)
175
0
7.7
1)
2)
13.8
15
295.6
309.4
15
6
169 175
15
279.4
15
Grounding screw M5
Connection socket
Note:
1) Add the height of the connector (15 mm) to this dimension
(24 + 15) = 39 mm
2) Pin for fixing the position (2∅4.7)
Fig. 5-7 Dimension drawing for the NC full keyboard (installed beneath the PCU)

Siemens SINUMERIK 802D sl Specifications

General

Brand	Siemens
Model	SINUMERIK 802D sl
Category	Controller
Language	English
