SIPOS SEVEN 2SA7 - Output 1

Operation instructions
SIPOS SEVEN: PROFITRON, HiMod
Page 72 Y070.302/EN
8 Parameters and possible parameter values
8.3 Parameters for the DCS
8
Parameters and possible parameter values
End position OPEN
The actuator has cut off in end position OPEN.
Torque CLOSE reached
Torque-dependent actuator cut-off in
CLOSE direction.
Torque OPEN reached
Torque-dependent actuator cut-off in OPEN
direction.
Torque CL/OP reached
Torque-dependent actuator cut-off in
CLOSE or OPEN direction.
Fault
A fault has occurred (for the type of fault
refer to chapter „4.3 Actuator status indica-
tion“ on page 18.
Blinker
The actuator operates. Signal changes be-
tween ‘high’ and ‘low’ state every 2 sec.
Ready
The actuator can be operated in "LOCAL"
and "REMOTE“ control mode.
Ready + REMOTE
The actuator can be operated in "REMOTE“
control mode.
Local
The actuator is in LOCAL control or OFF.
Intermediate contact CL
The actuator position is within the range
from 0 % to the position programmed as
"Intermediate contact CL" position, refer
also to Page 84.
Intermediate contact OP
The actuator position is within the range
from the position programmed as ‘Interme-
diate contact OP’ position to 100 %. Refer
also to Page 84.
Fault motor temperature
The max. motor temperature (155 °C) has
been exceeded.
For a menu overview, refer to illustration on the
right
The default setting shows the table on the next
page.
Not used
Signaling output 1 is not assigned a pos-
sible status message. “Output 1" is switched
off.
End position CLOSED
The actuator has cut off in end position
CLOSED.
Output 1
Control system
Torque CLOSE reached
Intermediate contact CL
Fault
Warning motor temp.
Run indication OPEN
Blinker + end position OP
Travel OPEN
Torque OPEN reached
Intermediate contact OP
Maintenance
Run indication OPEN/CLOSE
Torque CL/OP reached
Fault motor temperature
Run indication CLOSE
Blinker CL + end position CL
Travel CLOSE
Blinker
Fault external voltage
Normally Closed (NC)
Normally Open (NO)
Binary outputs
Not used
Signal assignment
Ready
Output 1
Output 2
End position CLOSED
Not used
Ready + REMOTE
End position OPEN
Local
Alternative control mode
Fig�: "Binary outputs” menu parameters
▼Signal
▼Signal
▼Level
