4 PRESENTATION
The products covered by this manual are available in two main versions:
1. Single door machine.
2. Double door machine.
In both versions the device is equipped with a touch screen user interface.
The touch screen allows the user to interact with the interface by touching icons on the screen to perform
actions based on the options available.
SINGLE DOOR MACHINE: the door to access the tank is used both to load the material to be processed
and to remove the finished load (after wash and thermal-disinfection treatment).
In the “single door” version there is only one touch screen for all the user interactive operations: select
and start program, machine parametrization, door lock and unlock.
DOUBLE DOOR MACHINE: the device has two doors to access the tank:
1. Loading door “unclean side”: used to load contaminated items to be treated with a wash cycle
and thermal disinfection in the device, in the washing cart.
2. Unload door or “clean side”: used to unload the treated, washed and thermally disinfected
items. Opening this door is only possible after a cycle has been successfully completed.
In the “double door” version there are two touchscreens: “unclean side” and “clean side”.
“Unclean side”: through the interface, the operator can select a wash, start the cycle, block a cycle, and
establish machine parameters.
“Clean side”: the operator can only unlock the door to unload items once the cycle has been completed
successfully. From the clean side it is also possible to interrupt a cycle in progress.
A cycle can be started only if the doors are closed.
