10.6 PROGRAM UNDER WAY - 1.1.1.3
During an ongoing cycle, the only possible action for the user is the cycle interruption, through the bottom right “STOP”
button.
The screen summarizes relevant data recorded by temperature probes, peristaltic pumps doses, remaining time. Next
to the “CLOCK” icon, the remaining cycle time is displayed. The icon flashes while cycle is active.
- Prewash -
.Structure: phase without any activation of heating elements or addition of chemical agents..
.Applications: used to remove larger spots and therefore to limit the formation of suds in the
following phases.
- Simple wash -
.Structure: Basic wash cycle that removes dirt from the load elements, accomplished through
appropriate dosage of chemical elements at controlled temperatures.
.Applications: this phase washes the load without disinfecting it.
- Wash with chemical disinfection -
.Structure: wash phase characterized by application of chemical elements with a bactericidal
effect on the load elements.
This cycle is generally not associated with any thermal disinfection phases.
N. current phase
of the cycle
During drying phase:
Value interpreted by
the TL probe
Icon that shows the
current cycle type:
drying
“STOP” button to
interrupt the cycle
Temperature
measured by TL
working probe
Temperature measured
by TCL control probe
Tmax: maximum wash temperature of
the cycle
Ao: Ao value that characterizes the
cycle.
N. current phase
of the cycle
Ao, current value of
the parameter
Remaining time of
the current cycle
Icon that shows
the cycle type
“STOP” button to
interrupt the cycle
