USER MANUAL
WD6010 – WD7010 – WD7015
Page 45 - 168
7.1.2 WD7010 - GW7010 – WD7015 – GW7015
ATTENTION
For all machines with sliding doors, opening of the detergent compartment disables the
automatic door opening system.
Always make sure that the two doors giving access to the detergent compartment are
properly closed before giving the command to open the loading side door.
To access the detergent compartment, open the
outer bottom door - loading side.
There is an additional metal panel protecting the jerrycan
compartment. This must be removed to access the jerrycans.
7.2 USE OF DETERGENTS
The machine is equipped with automatic devices for liquid detergent dosage.
1. Pump P1, liquid detergent dosage, neutral or weakly alkaline
2. Pump P2: acid neutralizer dosage.
3. Pump P3: optional.
4. Pump P4: optional.
5. Pompa P5: optional and installable only on 7015.
DOSAGE DEVICE
Standard Configuration
Pump function on
machines hospital sector -
WD
Pump function on
Laboratory device - GW
Color key
P1

Alkaline Detergent
Alkaline detergent
White
P2

Acid Neutralizer
Acid neutralising agent
Red
P3

Disinfectant
Optional - degreaser
Blue
P4

Lubricant
Optional – antifoam
Green
P5

Enzymatic detergent
Additional detergent
Yellow
Key:  present characteristic,  Optional characteristic, - non installable characteristic
WARNINGS
In case there are no level sensors in the jerrycan, periodically check the product level in the jerrycans
/ bottles to avoid running empty cycles.
During installation and after replacing the jerrycan, run an empty “SERVICE” program to load the
liquid. This refills the duct that runs from the jerrycan to the pump and ensures correct product dosage
in the following wash cycles.
