4.1 WD6010 and GW6010 - MACHINE WITH SWINGING DOOR
DEVICE VERSION
SINGLE DOOR MACHINE
There is a small lower door to access the detergent
compartment and the electricity supply disconnector.
DOUBLE DOOR MACHINE
IMPORTANT: in the double door version, on the load
side only, there is a lower door to access the detergent
compartment and the electricity supply disconnector.
“LOADING” SIDE VIEW of the device.
TOUCH SCREEN
INTERFACE
DOOR HANDLE
GLASS DOOR TO
ACCESS THE WASH
TANK
LOWER DOOR TO
ACCESS DETERGENT
COMPARTMENT
LOWER DOOR
HANDLE
