Smeg WD7010 - Wd7010 - Gw7010, Wd7015 - Gw7015 - Machine with Sliding Doors

USER MANUAL
WD6010 – WD7010 – WD7015
Page 16 - 168
4.2 WD7010 - GW7010, WD7015 – GW7015 – MACHINE WITH SLIDING DOORS
The sliding doors travel up and down to allow the operator access to the washing chamber for loading and
unloading of the instruments to be washed and disinfected.
Door opening and closure are activated by the user with the aid of the touch screen interface.
WD7010, GW7010
VIEW OF "UNCLEAN" SIDE (LOADING SIDE) of the device.
MAIN SWITCH ON-OFF
SWITCH
OPTIONAL
PRINTER
SAFETY KEY FOR SOLE USE
OF AUTHORISED
TECHNICAL STAFF
TOUCH SCREEN INTERFACE
USB PORT
