11.6 DIAGNOSTICS OPERATIONS – ID.1.4.3.0
Password-level required: technical staff only. Through these screens the device loads can be manually
activated and the load entries supervised. The screens are separated by operation:
Drum Water Loading – ID.1.4.3.1:
Solenoid valve activation
Check water turbine calculation
Check pressure switches status
Detergent loading – ID.1.4.3.2:
Detergent peristaltic pumps activation
Check flowmeter calculation
Check level sensors in the tank
Wash – ID. 1.4.3.5
Wash pump activation
Heater elements activation
Check temperature probes
Check pressure switches
Check thermostats status
Check sprinklers rotation sensors
Check carriages identification sensors
Drying – ID.1.4.3.3
Mechanical fan activation
Drying heater elements activation
Check temperature probes status
Check of thermostats status
Doors (hinged) – ID.1.4.3.8
Door lock activation, unclean side
Door lock activation, clean side
Check door lock status, unclean side
Check door lock status, clean side
Sliding doors – ID.1.4.4.3
Unclean side motor start
Clean side motor start
Unclean side limit switch check
Clean side limit switch check
"Doors locked" relay status check
Safety control unit status check
Drain – ID.1.4.4.0
Drain valve activation
Drain pump activation
Check pressure switches status
Check thermostats status
Boiler demi – ID.1.4.4.1
Demi loading valve activation
Boiler demi resistance activation
Boiler demi drainage solenoid activation
Check boiler temperature probe
Check boiler thermostats status
Check boiler water level
Boiler hot – ID.1.4.4.2
Hot loading valve activation
