Sony MLS-X1 - Setting the Independent Key Transition Rate

111
2 Select a transition type in the [Transition Type]
group.
Mix: Mi
x
Wipe: Wi
pe
DME Wipe: DM
E wipe
Cut: Cu
t
When an operation mode that supports configuration
o
f transitions where keys are inserted/removed
independently is set, select a transition type for key
insertion in the [ON Transition Type] group and a
transition type for key removal in the [OFF Transition
Type] group.
3 Set the transition type.
Make the required settings for the selected transition
t
ype.
When a mix, wipe, or DME wipe is selected
Set the transition rate.
For details about the transition rate, see “Setting the
Independent Key Transition Rate” (page 111).
When a wipe is selected
Set the wipe pattern.
For details, see “Setting an Independent Key
Transition Wipe” (page 158).
When a DME wipe is selected
Set the DME wipe pattern.
For details, see “Setting an Independent Key
Transition DME Wipe” (page 170).
Checking the independent key transition
type setting
On the ICP-X7000, you can check the transition type on
the display in the independent key transition execution
section of the transition control block, display in the
independent key transition control block, or display in the
key fader control block.
The transition type is indicated by the letters “M” (mix),
“W
” (wipe), “D” (DME wipe), and “C” (cut).
When the transition rate is set to timecode display, the
t
ransition type is not displayed.
Setting the Independent Key
Transition Rate
You can set the time taken from the beginning of an
independent key transition to its completion.
The independent key transition rate is configured using
t
he utility/shotbox control block and numeric keypad
control block, or the menu.
When an operation mode that supports configuration of
t
ransitions where keys are inserted/removed
independently is set, the transition rate for inserting and
removing keys can be set separately.
For details about independent key transition operation
mode, se
e “Setting the Independent Key Transition
Mode” (page 394).
Setting the independent key transition
rate (utility/shotbox control block and
numeric keypad control block)
When the utility/shotbox control block is switched to
transition rate display mode, the transition rate is
displayed in the memory recall section. Press a memory
recall button to select a transition rate, and set it using the
numeric keypad control block.
You can change the transition rate display mode
tr
ansition rate assignments.
For details, see “Setting Transition Rate Display Mode
Buttons” (page 405).
1 Press the [TRANS RATE1] button to [TRANS
RATE3] button in the utility/shotbox control block.
The memory recall section switches to transition rate
di
splay mode.
2 Press the memory recall button displaying the
transition rate of the target key to set, turning it on.
The target region name and transition rate to set are
shown
on the display of the numeric keypad control
block.
In operation modes that support configuration of
tr
ansitions separately for when keys are inserted/
removed, configuration while a key is not inserted
sets the transition rate for key insertion and
configuration while a key is inserted sets the
transition rate for key removal.
3 Enter a transition rate using the numeric keypad of the
numeric keypad control block.
You can switch the input mode using the [TC] button.
In frame number input mode, enter three digits. In
t
imecode input mode, enter four digits.
Note
Note
Note
