239
• When a preset color mix is selected on main or sub, it is
not possible to perform an independent key transition
operation on main and sub.
AUX Bus Functions
Selecting an AUX Bus/Edit Preview
Bus Signal
You can select and switch AUX bus and edit preview bus
signals using the menu.
From the list of cross-point button numbers, select the
but
ton number assigned with a signal.
In a multiple-box switcher configuration, signals other
th
an those sent to the cross-point box cannot be selected
on the AUX bus.
For details about sending to the cross-point box, see
“Setting Re-Entry Signals” (page 398).
1
Open the Home > Other Effects > Aux Bus > Aux Xpt
menu (18102.11).
2
Select the target bus for operation.
3
Press the [Edit] button.
A signal selection window for the selected bus
app
ears.
4
Select a video signal or key signal in [Select Source
Type].
To select a video signal, set the [Video] radio button
to
the on state.
To select a key signal, set the [Key] radio button to
t
he on state.
5
Switch the signal using the cross-point selection
buttons.
Select a tab to change the button number to display.
Setting a cross-point selection button to the on state
swi
tches the cross-point.
AUX Mix
In addition to a switcher bank transition, you can also
perform a transition between two AUX buses.
Assigning AUX buses to outputs for an
AUX mix
Assign two AUX buses used for an AUX mix to
consecutive odd-numbered and even-numbered outputs.
Note
