Maintenance
Status Information
You can check the status of the switcher system using the
menu.
The following icons are displayed according to the status.
: Operating normally.
: Operation not affected, but caution is required.
: Error occurred which requires a response.
The number of messages is displayed on the messages
i
ndicator button in the header area when there is updated
error information. Press the messages indicator button to
check information about the occurrence and resolution of
errors.
When not connected to the network, the status display is
bl
ank.
Displaying Error Information
You can check the errors and current status of the
switcher system.
The following information is displayed.
Item: Item name
Value: Current value
Status: Status icon
Latest Error Date/Time: Date and time the latest error
o
ccurred
Switcher
1 Open the Home > Maintenance > Status > Error
Status > Switcher menu (19201.11).
2 Select a [Logical Box ID] radio button to change the
box to display.
In a 2M/E, 3M/E, and 4M/E box switcher
co
nfiguration, the [XPT Box] radio button is
displayed. Select [XPT Box] to check the error
information for the cross-point box.
3 Select a tab to change the item to display.
[PSU] tab: Po
wer supply unit status
[Fan] tab: F
an status
[Board] tab: Board st
atus
[Reference] tab: Referenc
e signal status
[Temperature] tab: C
PU and board temperature
status
[Network] tab: Networ
k status
[Boot] tab: S
tartup status
[Local I/F] tab: L
ocal interface status
[100G IP I/F] tab: 100
G IP interface status
Control panel
Open the Home > Maintenance > Status > Error Status >
Panel menu (19201.12).
You can check the power supply and connection status of
t
he control panel.
Software
Open the Home > Maintenance > Status > Error Status >
Software menu (19201.13).
You can check the software and memory status.
Displaying Remote Panel Status
When using the network AUX remote panel function, you
can check the status of the connected remote panel.
Open the Home > Maintenance > Status > Error Status >
Aux R
emote Panel menu (19201.14).
The following information is displayed.
Name: Remote panel name
IP Address: IP address of remote panel
Status: Status icon
Note
Note
