98
Setting Key Priority
Setting the key priority (transition control
block)
You can set the key priority using the transition control
block of the target switcher bank.
The buttons used for configuring the key priority must be
assi
gned to the transition control block beforehand.
For details about assigning buttons, see “Assigning
Control Panel Buttons” (page 402).
1
Press and hold the [PRIOR SET] and press the [KEY
PRIOR] button to select the target key priority
(current key priority or key priority for after the
transition) to set.
When the [KEY PRIOR] button is lit green, the key
pr
iority setting for after the transition is selected.
When the [KEY PRIOR] button is not lit, the current
key priority setting is selected.
2
Set the key to display at the front.
Press and hold the [PRIOR SET] button and press a
[
KEY1] to [KEY8] button.
The selected key is set to be frontmost (priority 1).
To set the key priority for after the transition to the
same
setting as the current setting, press and hold the
[PRIOR SET] button and press the [BKGD] button.
The [BKGD] button is enabled only when in the
mod
e for changing the key priority for after the
transition.
3
Repeat steps 1 and 2 to set the key priority, as
required.
Setting the key priority (menu)
This section describes the M/E-1 menu as an example.
1
Open the Home > M/E-1 > Common > Key Priority/
Key Assign menu (11110.11).
2
Select the target key priority (current key priority or
key priority for after the transition) to set.
When setting the current key priority
Press the [Edit] button for [Current Key Priority]. The
[
Current Key Priority] window appears.
When setting the key priority for after the
tra
nsition
Press the [Edit] button for [Next Key Priority]. The
[Ne
xt Key Priority] window appears.
3
Set the buttons for the keys to set to priority 1 to 8 to
the on state in [Priority 1] to [Priority 8].
The priority options available for selection vary
dep
ending on the number of keys assigned to a
switcher bank.
4
Press [OK].
Checking the key priority settings
The key on/off status and priority status are shown on the
display of the transition control block.
In the transition control block of the ICP-X1000 series,
th
e key on/off status and priority status are shown only
while setting the key priority (while the [PRIOR SET]
button is pressed).
Key on/off status display
When a key is inserted, [K1] to [K8] are displayed
hi
ghlighted.
Key priority display
The numbers 1 to 8 (priority 1 to 8) are displayed under
th
e on/off status indicators for each key.
If the [KEY PRIOR] button is selected, the priority (1 to
8)
of keys for after the transition are displayed highlighted
on the right of the current priority. The key priority for
after the transition is not displayed if the values are the
same as the current priority setting.
In the transition control block of the ICP-X7000, only the
p
riority status for after the transition is shown while
setting the key priority for after the transition.
Note
Note
Note
Note
Note
To Next Page
