To release a macro attachment set to a fader
lever
Press and hold the [PRE MACRO] button or [POST
MAC
RO] button in the cross-point control block and
press the [LIMIT SET] button or [PRIOR SET] button in
the transition control block/transition control block
(simple type).
You can also release a macro attachment setting using the
menu
.
For details, see “Displaying a Macro Attachment List”
(page 325).
Setting the macro attachment
configuration mode of a cross-point
button
The following two modes can be selected for a macro
attachment set to a cross-point button.
Button number mode: Assign a macro attachment for the
co
mbination of bus and button number.
Pair number mode: Assign a macro attachment for the
co
mbination of bus and logical V/K pair number.
• If the macro attachment configuration mode is changed,
t
he macro attachment assigned to a cross-point button is
deleted.
• In pair number mode, the following occurs.
– If the same logical V/K pair number is assigned to
m
ultiple cross-point buttons, pressing one of the
buttons executes the macros of all buttons to which
the same logical V/K pair number is assigned.
– If the same logical V/K pair number is assigned to
m
ultiple cross-point buttons, releasing the macro
attachment of one of the buttons releases the macro
attachment of all buttons to which the same logical
V/K pair number is assigned.
– If you change the logical V/K pair number
assi
gnment to a different cross-point button, the
macro attachment setting is also transferred.
• When macro attachment data is loaded, the button
nu
mber mode or pair number mode setting is
overwritten.
1
Open the Home > Register > Macro > Attachment
menu (18307.31).
2
In the [Xpt Attachment Mode] group, select a
configuration mode.
Button Mode: B
utton number mode
Pair Mode: P
air number mode
3
Check the message, then press [OK].
Displaying a Macro Attachment List
You can check the information for a button/fader lever to
which a macro attachment is set in list view.
1
Open the Home > Register > Macro > Attachment
menu (18307.31).
2
Display the target control block.
Select a tab to change the control block to display.
[M/E-1] tab to [M/E-5] tab, [P/P] tab: S
witcher
bank cross-point control block and transition
control block/transition control block (simple
type)/independent key transition control block
[Aux] tab: AUX bus co
ntrol block (ICP-X7000 only)
[Trackball] tab: Devi
ce control block (ICP-X1000
series only)
[Trackball/Key Fader] tab: Dev
ice control block
and key fader control block (ICP-X7000 only)
A list of the macro attachments set to the buttons of
t
he selected control block is displayed.
You can check the following information in a macro
at
tachment list.
•Block name
Displays the name of the control block on which macro
at
tachments are set.
• Buttons to which a macro attachment is set
•Register number
•Register name
• Link mode
For details about macro attachment lists, see “Macro
Attachment Lists” (page 525).
Macro attachments set to the following buttons in the
cr
oss-point control block may not be displayed in the list.
• DME utility 1 bus and 2 bus cross-point buttons in
ut
ility bus mode
• DME utility 1 bus and 2 bus cross-point buttons in key/
AU
X bus delegation mode
Releasing a macro attachment
1
Open the Home > Register > Macro > Attachment
menu (18307.31).
2
Display the target control block.
Select a tab to change the control block to display.
Note
Notes
Note
