Setting an Independent
Key Transition DME Wipe
DME wipe patterns and modifiers for independent key
transitions are configured using the menu.
This section describes the M/E-1 key 1 menu as an
e
xample.
Setting a DME Wipe Pattern for an
Independent Key Transition
In an independent key transition, wipe pattern parameters
cannot be adjusted.
Selecting a DME wipe pattern
1
Open the DME wipe pattern selection menu.
In 1-channel mode, open the Home > M/E-1 > Key1
>
Transition > 1ch Pattern menu (11101.54).
In 2-channel mode, open the Home > M/E-1 > Key1
>
Transition > 2ch Pattern menu (11101.55).
2
Press the button for a DME wipe pattern group.
The patterns in the selected group are displayed.
For 1-channel mode
Select from the following DME wipe pattern groups.
Slide / Squeeze: S
lide and squeeze
Split / Door: Spl
it and door
Page Turn: Pa
ge turn
Roll: Ro
ll
Frame I/O: Fr
ame in/out
Resizer Slide / Squeeze: Resi
zer slide and squeeze
Resizer Frame I/O: Resi
zer frame in/out
For 2-channel mode
Select from the following DME wipe pattern groups.
Page Turn: Pa
ge turn
Roll: Ro
ll
3
Set the button for the target wipe pattern to the on
state.
Setting Independent Key Transition
DME Wipe Modifiers
For details about the supported modifiers, see “Setting
Modifiers” (page 166).
Setting the DME wipe direction (Direction)
1
Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2
In the [Direction] group, select a DME wipe
direction.
Normal: DME
wipe in normal direction.
Normal/Reverse:
Alternate directions between
normal and reverse after each transition.
Reverse:
DME wipe in the opposite direction of the
normal direction.
Modifying a DME wipe pattern edge
(Edge)
1
Open the Home > M/E-1 > Key1 > Transition > DME
Wipe menu (11101.53).
2
In the [Edge] group, select a type of edge.
Border: A
dds a border to a pattern.
Soft Border: So
ftens a border applied to a pattern.
When the [Border] button is selected, set the
fo
llowing parameters.
When the [Soft Border] button is selected, set the
fo
llowing parameters.
Note
No. Parameter Adjustment
1 Width Border width
3 Luminance Luminance
4 Saturation Saturation
5 Hue Hue
No. Parameter Adjustment
1 Width Border width
2 Inner Soft Softness of inner edge of
bo
rder
3 Luminance Luminance
4 Saturation Saturation
5 Hue Hue
