Sony MLS-X1 - Editing a Snapshot Register

287
The [Edit Auto Play] window appears.
2 Set the button for the target channel to the on state.
You can select multiple channels.
3 Press [OK].
To add the cross-point hold (DME) attribute
Set the [Xpt Hold] switch to the on state.
Editing a Snapshot Register
You can copy, move, and swap register data. You can also
rename, lock, and delete a register.
Copying, moving, and swapping registers between
di
fferent regions is supported between the following
regions.
• Between switcher bank regions (M/E-1 to M/E-5, P/P,
M/
E-1 Sub to M/E-5 Sub, P/P Sub)
• Between DME regions (DME 1 to DME 4)
Copying a register
• An empty register cannot be copied.
• A locked register cannot be copied.
1 Open the Home > Register > Snapshot > Edit
Register > Copy/Move/Swap menu (18302.13).
A list of copy source registers is shown on the left,
an
d a list of copy destination registers is shown on the
right.
2 Press the [Select] button in the [Region] group on the
left.
The [Select Region] window appears.
3 Set the button for the copy source region to the on
state.
Select a tab to change the region to display.
[ME] tab: Swi
tcher bank regions
[User] tab: User
regions
[DME] tab: DM
E regions
[External Device] tab: E
xternal device regions
4 Press [OK].
5 In the list on the left, select a copy source register.
To select and copy multiple registers, place a check
mar
k beside the target registers to copy.
To select and copy all registers, place a check mark in
t
he Select All checkbox.
You can also press the [Select Register(s)] button and
ent
er a register number in the numeric keypad
window.
6 Press the [Select] button in the [Region] group on the
right.
The [Select Region] window appears.
7 Set the button for the copy destination region to the
on state.
Select a tab to change the region to display.
8 Press [OK].
9 In the list on the right, select a copy destination
register.
When multiple registers are selected, select the first
cop
y destination register.
You can also press the [Select Destination] button
and
enter a register number in the numeric keypad
window.
The copy destination of the first register selected on
th
e left is the first register selected on the right, and
the subsequent registers on the right in the same
relative positions as the selected registers on the left
become copy destinations. The first register on the
right is shown in light blue, and the subsequent copy
destination registers are shown in blue gray.
10 Press the [Copy] button.
11 Check the message, then press [OK].
To search for a register
Press the [Search] button, enter a character string to
sear
ch for in the input field in the displayed window, and
press the [Enter] button.
Only registers containing the entered character string are
di
splayed.
To copy without renaming a destination register
Set the [w/o Name] button to the on state.
Moving a register
• An empty register cannot be moved.
• A locked register cannot be moved.
Select a move source register and move destination
regi
ster in the same way as for copying a register and
press the [Move] button.
For details, see “Copying a register” (page 287).
