For details about settings, see “Enabling double-press
for the [BKGD] button in the transition control block”
(page 418).
To change the key overlay sequence
Press the [KEY PRIOR] button.
Set the key priority for after the transition.
For details about key priority, see “Key Priority”
(page 97).
To select multiple preconfigured next
t
ransitions simultaneously
Press the [ALL] button.
For details about setting next transitions selected
si
multaneously, see “Setting the next transitions to select
using the [ALL] button in the transition control block”
(page 418).
Key Priority
When multiple keys are inserted, you can set the overlay
sequence of the keys.
When the [KEY PRIOR] button is selected in a next
tr
ansition, depending on the transition, the key overlay
sequence changes.
The key overlay sequence is set by key priority values 1
to
8, numbered from the front to the rear.
The key priority can be set using the transition control
bl
ock or the menu.
• In the simple-type transition control block, key priority
cann
ot be configured.
• When the operation mode of the switcher bank is set to
mul
ti program mode or multi program 2 mode, the key
priority cannot be changed, depending on the transition.
• The key priority cannot be configured in fixed mode.
For details, see “Setting the Key Priority Mode”
(page 396).
• The current key overlay sequence can be checked on
th
e program output of the switcher bank.
When the [KEY PRIOR] button is selected in a next
t
ransition, the key overlay sequence for after the
transition can be checked on the preview output of the
switcher bank.
Key priority of SL keys
SL keys 5 to 8 are assigned the priority of four keys as a
sin
gle group.
Within SL keys 5 to 8, you can set any priority.
Example:
Overlay keys in the sequence key 1, key 2, SL keys 5 to
8, ke
y 3, key 4
Set the priority as follows.
Priority 1: Key 1
Priority 2: Key 2
Priority 3 to 6: SL keys 5 to 8 (priority 3 to 6 can be
assi
gned arbitrarily within SL keys 5 to 8)
Priority 7: Key 3
Priority 8: Key 4
When the system signal format is 2160P, the SL key
f
unction must be enabled for use.
For details about settings, see “Setting a GPU”
(page 363).
