Chapter
452
30
System Configuration
and Management
System Configuration menu
This menu is used to check network settings and the
components of the switcher system, and to create user
accounts.
Administrator privileges are required for some menu
op
erations.
For details about system configuration, refer to the
ML
S-X1 Installation Manual.
Checking System
Configuration Devices
Checking devices configured in a system
You can display the network settings for the boxes and
control panel configured in a switcher.
• For a box (MLS-X1), the Ctrl LAN network settings are
di
splayed.
• For the ICP-X7000, information is detected for each
cont
rol panel row. The name of the module located on
the right side of each row is displayed in [Device Type].
If there is no module located in a control panel row,
“MKS-7099” (CPU module name) is displayed.
1
Open the System Configuration > Configuration >
System menu (20101.11).
2
Press the [Display] button.
For a box:
The [Box Ctrl LAN Settings] window appears.
You can check the standard network interface 1
se
ttings of the boxes.
For details about configuring box network settings,
see “Configuring Box Network Settings” (page 470).
For a control panel:
The [Panel Bank Network Settings] window appears.
You can check the network settings of the control
pan
el.
For details about settings, see “Configuring Control
Panel Network Settings” (page 474).
Notes
