Setting a Tally Group
You can select a tally group (1 to 8) controlled using NS-
Bus. You can set multiple tally groups.
1 Open the Home > Setup > Router/Tally > Tally >
Group Tally menu (19106.21).
2 In the [Tally Group] group, select a tally group
(Group 1 to Group 8).
3 Enable/disable the tally using the [NS-Bus Tally
Enable] button.
On:
Enable tally control using NS-Bus.
Off: Disa
ble tally control using NS-Bus.
Setting Wiring
You can set output and input connection information
(wiring) in NS-Bus space.
The wiring settings are common to both parallel tally and
se
rial tally.
1 Open the Home > Setup > Router/Tally > Tally >
Wiring menu (19106.22).
2 Select the target wiring to set.
To select and set multiple wiring, place a check mark
besi
de the target wiring to set.
You can also press the [Select Number(s)] button and
ent
er a wiring number in the numeric keypad
window.
The maximum number of wiring settings that can be
se
t at the same time is 128.
3 Press the [Source] button and enter an address for a
source in the numeric keypad window.
If multiple consecutive wiring settings are selected,
con
secutive addresses from the entered address are
set.
4 Press the [Src Level] button and enter a source level
(1 to 8) in the numeric keypad window.
5 Press the [Destination] button and enter an address
for a destination in the numeric keypad window.
If multiple consecutive wiring settings are selected,
con
secutive addresses from the entered address are
set.
6 Press the [Dest Level] button and enter a destination
level (1 to 8) in the numeric keypad window.
To delete wiring settings
Select the target wiring to delete and press the [Delete]
but
ton.
