Sony MLS-X1 User Manual

114
Executing an independent key transition
(key fader control block)
You can execute an independent key transition for a key
assigned to a key delegation button.
For details about assigning key delegation buttons, see
“Assigning Control Panel Buttons” (page 402).
To insert/remove a key instantaneously
Press the [KEY ON] button.
The [KEY ON] button label indicates the key assigned to
t
he key delegation button.
To insert/remove a key with the preset transition
ty
pe and transition rate
Press the [AUTO TRANS] button for the corresponding
key
.
During the transition execution, the button is lit amber
and
goes off when the transition is completed.
• You can change this so that during the execution of the
t
ransition, the button is lit green and when the transition
is completed it is lit red if on-air or lit amber if not on-
air.
For details about settings, see “Setting the independent
key transition, auto transition execution button
display” (page 417).
• When a cut is selected as the transition type, the key is
in
serted/removed instantaneously.
To insert/remove a key manually with the preset
tra
nsition type
Operate using the fader lever.
You can set the key which is the target of fader lever
op
eration.
For details about setting the fader lever, see “Assigning
Control Panel Buttons” (page 402).
Executing an independent key transition
(menu)
This section describes the M/E-1 key 1 menu as an
example.
1 Open the Home > M/E-1 > Key1 > Key Snapshot
menu (11101.71).
2 Execute a transition.
To insert/remove a key instantaneously
Press the [KEY ON] button.
To insert/remove a key with th
e preset transition
type and transition rate
Press the [KEY TRANS] button.
When a cut is selected as the transition type, the key
i
s inserted/removed instantaneously.
Note
Notes
Note
Note
