295
A key snapshot cannot be registered using the numeric
keypad control block.
1
Recall an effect timeline register/snapshot register to
register in a shotbox.
To register an effect timeline register
Press the [EFF] button to switch to effect timeline
o
peration mode and select the target register to
register for each region.
For details about the method of operation, see
“Recalling an Effect Timeline” (page 256).
To register a snapshot register
Press the [SNAPSHOT] button to switch to snapshot
o
peration mode and select the target register to
register for each region.
For details about the method of operation, see
“Recalling a Snapshot” (page 281).
2
Press the [SHOTBOX] button.
The [SHOTBOX] button and [RCALL] button turn
o
n amber, and the numeric keypad control block
switches to shotbox operation mode.
3
Press the [STORE] button.
The [RCALL] button turns off and the [STORE]
b
utton turns on amber.
The [EFF] button (for an effect timeline) or the
[SN
APSHOT] button (for a snapshot) turns on green.
If the [EFF] button/[SNAPSHOT] button does not
t
urn on, press the [EFF] button/[SNAPSHOT] button,
turning it on green.
4
Select a region for the effect timeline/snapshot to
register in the shotbox using the region selection
buttons.
Press the region selection button, turning it on, for the
targ
et region to register.
For details about selecting a region, see “Selecting a
region” (page 255).
5
Enter a shotbox register number in the numeric
keypad area.
6
Press the [ENTER] button.
The [STORE] button turns off and the [RCALL]
b
utton turns on amber.
Editing a shotbox
You can change an effect timeline/snapshot register and
the region to register in a shotbox.
1
Press the [SHOTBOX] button.
The [SHOTBOX] button and [RCALL] button turn
on
amber, and the numeric keypad control block
switches to shotbox operation mode.
2
Recall the target shotbox register to edit.
Enter a register number in the numeric keypad area
and
press the [ENTER] button.
3
Change the effect timeline register/snapshot register
registration.
To change an effect timeline register registration
Press the [EFF] button to switch to effect timeline
ope
ration mode and select the target register to
register for each region.
For details about the method of operation, see
“Recalling an Effect Timeline” (page 256).
To change a snapshot register registration
Press the [SNAPSHOT] button to switch to snapshot
ope
ration mode and select the target register to
register for each region.
For details about the method of operation, see
“Recalling a Snapshot” (page 281).
4
Press the [STORE] button.
The [RCALL] button turns off and the [STORE]
but
ton turns on amber.
The [EFF] button (for an effect timeline) or the
[S
NAPSHOT] button (for a snapshot) turns on green.
To delete the region for an effect timeline/
sna
pshot registered in a shotbox
Press the region selection button, turning it off, for the
t
arget region to delete.
To check the region for an effect timeline
regi
stered in a shotbox
While the [EFF] button is lit, press and hold the
[S
TORE] button. While the [STORE] button is
pressed, the region selection button for the region in
which the effect timeline is registered is lit amber.
To check the region for a snapshot registered in a
sh
otbox
While the [SNAPSHOT] button is lit, press and hold
th
e [STORE] button. While the [STORE] button is
pressed, the region selection button for the region in
which the snapshot is registered is lit amber.
Note
Note
