Sony MLS-X1 User Manual

34
a Key delegation buttons
There are four key delegation buttons (1 to 4) in the order
t
op left, top right, bottom left, and bottom right.
You can assign keys of any switcher banks (M/E-1 to
M/E-5, P/P) in the Home > Setup > Panel > Module >
B
utton Assign menu (19104.21).
For details about assigning buttons, see “Assigning
Control Panel Buttons” (page 402).
b I
ndependent key transition execution section
The four [KEY ON] buttons and [AUTO TRANS]
bu
ttons correspond to the keys assigned to key delegation
buttons 1 to 4.
The [KEY ON] button label indicates the key assigned to
t
he key delegation button.
c I
ndependent key transition type selection buttons
d Key sn
apshot operation buttons
e Di
splay
Displays the following information for each key assigned
to
a key delegation button.
• Key content name (key source name when a key source
is
selected on a cross-point control block key bus)
• Currently used DME channel or resizer
• Transition rate
• Transition type
• Register name (in key snapshot operation mode).
For details about the content name display of keys, see
“Setting Logical V/K Pair Names/Source Names and
Destination Names” (page 416) and “Setting a Logical
V/K Pair” (page 381).
Name Description
Fader lever Move this up or down to execute a
t
ransition.
Transition indicator Displays the transition progress
u
sing LEDs.
[KEY ON] button Inserts or removes a key
i
nstantaneously.
When a key is currently inserted,
t
he button is lit amber.
[AUTO TRANS]
bu
tton
Inserts or removes a key
automatically with the set transition
rate and transition type.
During the transition, the button is
l
it amber.
Note
Button name Description
MIX Selects mix.
WIPE Selects wipe.
Transition indicator
KEY ON buttons
AUTO TRANS buttons
Fader lever
DME WIPE Selects DME wipe.
CUT Selects cut.
SHIFT Use when setting transitions separately for
k
ey insertion and removal.
Button name Description
K-SS 1 to
K-SS 4
Selects key snapshot register 1 to 4.
K-SS Switches to key snapshot operation mode.
K-SS STORE Saves a key snapshot in the selected
re
gister when a [K-SS 1] to [K-SS 4] button
is pressed while pressing the [K-SS
STORE] button.
UNDO Undoes a key snapshot recall if pressed
i
mmediately after the recall.
Button name Description
