362
• Home > Register > Effect Timeline (switcher banks,
users, DME regions only)
• Home > Register > Snapshot (switcher banks, users,
DME
regions only)
• Home > Register > Key Snapshot
• Home > Register > Wipe Snapshot
• Home > Register > DME Wipe Snapshot
• Home > Setup > System > Input
• Home > Setup > System > Output
• Home > Setup > System > 100G IP Input/Output
• Home > Setup > System > V/K Pair > Physical V/K
P
air Assign
• Home > Setup > System > Source > Edit Source Name
• Home > Setup > Xpt Assign > V/K Pair > Logical V/K
P
air Assign
• Home > Setup > Xpt Assign > V/K Pair > Edit Logical
V/K P
air Name
• Home > Setup > Xpt Assign > V/K Pair > Copy Logical
V/K P
air Name
• Home > Setup > Xpt Assign > V/K Pair > Logical V/K
Pa
ir Color
• Home > Setup > Xpt Assign > Xpt Delay
• Home > Setup > Switcher > Config > PGM Config
• Home > Setup > Switcher > Config > K-PVW Config
• Home > Setup > Switcher > Config > DSK Bkgd
Assign
• Home > Setup > Switcher > Config > DME Config
• Home > Setup > Switcher > Config > User Region
C
onfig
• Home > Setup > Switcher > Multi Viewer
• Home > Setup > Switcher > DME Interface
• Home > Setup > Switcher > Custom
• Home > Setup > Switcher > Box Settings
• Home > Setup > Link > Internal Bus Link
• Home > Setup > Link > M/E Link
• Home > Setup > Link > Key Transition Link > Link in
Mu
lti M/Es
• Home > Setup > Link > Aux Bus CCR Link
When dual simul mode is enabled with a combination of
“21
60P and 1080i” or “1080P and 1080i” system signal
formats, the following operations can be linked for frame
memory and clip players.
• Home > Frame Memory > FMx/FMx > Clip/Still >
R
ecall menu (FMx/FMx = FM1/FM2 to FM15/FM16):
[Audio On] switch
[Output Lock] switch
[Group Mode] button
• Home > Frame Memory > FMx/FMx > Clip/Still > Play
men
u (FMx/FMx = FM1/FM2 to FM15/FM16):
[Audio On] switch
[Output Lock] switch
Move to start of video content
Move to video playback start point
Reverse playback
Pause playback
Playback
Move to video playback stop point
Move to end of video content
[Variable Speed] button
[Set Loop Playback] button
• Home > Clip Player > Clipx/Clipx > Clip > Recall
m
enu (Clipx/Clipx = Clip1/Clip2 to Clip3/Clip4):
[Audio On] switch
[Output Lock] switch
[Group Mode] button
• Home > Clip Player > Clipx/Clipx > Clip > Play menu
(
Clipx/Clipx = Clip1/Clip2 to Clip3/Clip4):
[Audio On] switch
[Output Lock] switch
Move to start of video content
Move to video playback start point
Pause playback
Playback
Move to video playback stop point
Move to end of video content
[Variable Speed] button
[Set Loop Playback] button
Dual simul mode taskbar
The following taskbars can be operated for two switchers
at
the same time.
The control targets are switcher banks, users, and DME
r
egions only.
• [Effect Timeline Recall/Store]
• [Effect Timeline Edit]
• [Snapshot]
Note
