44
For details about the method of operation, see “Cross-
point pad operation” (page 22).
Assignable functions
Function name Button
name
Description
Others:
Home
HOME Displays the home page
o
f the cross-point pad.
Others:
Prev
<< XXX Displays the previous
p
age of the cross-point
pad.
XXX = Page name (up to
12
characters)
Others:
Next
>> XXX Displays the next page of
t
he cross-point pad.
XXX = Page name (up to
12
characters)
Others:
Current Page
Sta
tus
PAGE 1
XXX to
PAG
E14
XXX
Displays the number and
name of the currently
displayed page.
XXX = Page name (up to
12
characters)
Others:
Row-n Assign
Sta
tus
XXX Displays the bus/function
n
ame assigned to the 1st
row to 4th row.
When a destination
w
hose operation is
inhibited using the
NS-Bus protect function,
“PROT” is displayed for
the 3rd row/4th row.
n = 1 to 4
XXX = Bus or function
na
me
Others:
Xpt Hold
a)
XPT HOLD Sets cross-point hold for
the 3rd row and 4th row.
In second delegation
m
ode, sets cross-point
hold for the 3rd row.
Others:
2nd Xpt Hold
a)
XPT HOLD In second delegation
mode, sets cross-point
hold for the 4th row.
Row-3/4 Func:
Row-n Xpt Button
No.2
85 to Xpt
Button No.300
a)
XXX Selects the cross-point
button number 285 to 300
signals in the 3rd row and
4th row.
Re-entry signals (M/E-1
t
o M/E-5 Out1, P/P Out1,
M/E-1 to M/E-5 Out5, P/P
Out5) are assigned to
button numbers 285 to
290 and 293 to 298.
n = 3 or 4
XXX = Signal name
Others:
Selected Src
Statu
s
XXX Displays the signal name/
s
ource name selected by
the bus/destination on the
1st row or 2nd row
delegation buttons.
In second delegation
m
ode, displays the signal
name/source name
selected by the bus/
destination on the 1st row
delegation buttons.
XXX = Signal name/
s
ource name
Others:
2nd Selected Src
Statu
s
XXX In second delegation
m
ode, displays the signal
name/source name
selected by the bus/
destination on the 2nd
row delegation buttons.
XXX = Signal name/
s
ource name
Others:
Display Mode 1 to
Di
splay Mode 6
XXX Selects display mode 1 to
6 (display mode button).
XXX = Display mode
na
me (up to 12
characters)
Others:
Display Mode
Statu
s
DISP: XXX Displays the currently set
di
splay mode.
XXX = Display mode
na
me (up to 12
characters)
Macro:
Macro 1: XXX to
Ma
cro 999: XXX
XXX Recalls macro register 1
to
999.
XXX = Macro register
na
me (up to 8 characters)
Others:
Macro Take
TAKE Executes a macro take
op
eration.
Others:
Macro Register
Statu
s
MACRO:
XXX
Displays the currently
recalled macro register
name.
The macro register name
(ATT
CH: XXX) of the
macro attachment is
displayed while the [PRE
MACRO] button or [POST
MACRO] button is
pressed.
XXX = Macro register
na
me (up to 8 characters)
Others:
Macro Status
EVENT
XX/XX
Displays the macro
st
atus.
XX/XX = Executed event
nu
mber/Total number of
events
Others:
Aux Mix
a)
AUX MIX Executes an AUX mix on
the 3rd row and 4th row.
In second delegation
mode, executes an AUX
mix on the 3rd row.
Function name Button
name
Description
