524

XptTableForRow MEBank ME1 to ME5, PP

ME1Sub to ME5Sub, PPSub

Switcher bank

Row 1st, 2nd, 3rd, 4th, 3rd&4th, All Button row

Table Table1 to Table14

BankTable

Cross-point assign table

• “BankTable” = Table being set in switcher

MacroTake Register All Register

• “All” = all paused macros

MacroCancel Register All Register

• “All” = all simultaneously executing

cros

PrevKF Region Current Region

• “Current” = currently selected region

NextKF Region Current Region

• “Current” = currently selected region

TransitionRate ME ME1 to ME5, PP Switcher bank

Transition Background, BackgroundSub

Key1 to Key8

Transition

Time 0 to 999

Transition rate (number of frames)

Symbol Parameter Parameter setting values Description
