Chapter 22 DCU Setup (DCU)
1282
Serial Port Settings (Serial Port Assign Menu)
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) 1. Maximum Open Delay: maximum time required to open a file
2. Maximum Cueup Delay: maximum time required to cue up a file
3. Play After Cueup Delay: delay time from the cued-up state to begin playback
4. Play After Open Next Delay: delay time from the Open Next state to begin playback
5
Turn the knob to set the disk recorder response speed.
6
Press [Set].
This confirms the setting.
7
Repeat steps 4 to 6 as required to make the settings for other items.
Making detailed settings for a disk recorder (video disk
communications protocol)
1
In the <DCU Select> group of the DCU >Serial Port Assign menu, select
the target for the setting (DCU1 or DCU2).
2
Using any of the following methods, select the serial port connected to the
disk recorder for which you want to make settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) The range of setting values depends on the DCU port setting. (When the MKS-2700 is
connected, select 2 for the slot and a value in the range 1 to 6 for the port.)
3
Press [Port Setting].
When “DDR VDCP” is selected as the protocol, the DCU >Serial Port
Assign >DDR VDCP Setting menu appears.
Knob Parameter Adjustment Setting values
1 Item No Item selection
1 to 4
a)
Knob Parameter Adjustment Setting values
2 Setting Response speed setting 0 to 255
Knob Parameter Adjustment Setting values
1 Port No Serial port
1 and upwards
a)
To Next Page
