Chapter 3 Signal Selection and Transitions
155
Signal Selection
• The source name displays in the cross-point control block and auxiliary bus
control block show the source names of the video signals assigned to
numbers 1 to 31.
• To display the source names for numbers 32 to 62, press the [SHIFT] button
to the right of the source name displays.
• To display the source names of the key signals assigned to buttons, hold
down the [SPLIT] button in the key control block or the [KEY] button in the
auxiliary bus control block.
When using the AUX panel-less function (see page 150) with the CCP-6224/
6324 Control Panel, you can use the cross-point control block as an AUX bus
control block with the [AUX CTRL] button.
In this case, use the key 1 row as AUX delegation buttons, and the key 2 row
as AUX bus cross-point selection buttons; the source name displays show the
bus names and source names.
Colors of lit cross-point buttons
In a particular row of cross-point buttons, only the last pressed button is
effective, and lights amber or red. The amber indicates the “low tally” state,
and the red indicates the “high tally” state, to indicate whether or not the
selected signal appears in the final output video.
Significance of colors of lit cross-point buttons
Color State Significance
Amber Low tally Does not appear in final output video
Red High tally Appears in final output video
