Chapter 4 Keys
239
Key Setting Operations Using Menus
• When turning [Multi] on and replicating the pattern
a) See page 307.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 306.
• When turning [Angle] on in the <Rotation> group and setting the
angle of the pattern rotation
a) See page 304.
• When turning [Speed] on in the <Rotation> group and setting the
rate of pattern rotation
a) See page 305.
Using the subsidiary mask
For example, to use the subsidiary mask for key 1 on the M/E-1 bank, use the
following procedure.
1
In the M/E-1 >Key1 menu, select HF4 ‘Sub Mask.’
The Sub Mask menu appears.
2
In the <Mask Type> group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally
1 to 63
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Pattern angle
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rate of pattern rotation
–100.00 to +100.00
a)
