Chapter 8 Color Backgrounds, Copy and Swap, and Other Settings
440
Color Background
4 If required, set the pattern modifiers.
• When turning [Position] on and setting the pattern position
a) See page 302.
• When turning [Multi] on and using replications of the same pattern
a) See page 307.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 306.
• When turning [Pairing] on and making a wipe pattern like a
Venetian blind
• When turning [Angle] on in the <Rotation> group and slanting the
pattern
a) See page 304.
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
a)
2 Position V Vertical position
–200.00 to +200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally
1 to 63
2 V Multi Number of repetitions of pattern
vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Width Width of the slits 1 to 128 (integer)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation
–100.00 to +100.00
a)
