Chapter 16 Macros
981
Macro Attachment Assigning
Block Button
Cross-point control block • Background A row cross-point buttons
• Background B row cross-point buttons
• Key 1 bus cross-point buttons
• Key 2 bus cross-point buttons
• Key 3 bus cross-point buttons
• Key 4 bus cross-point buttons
• Utility 1 bus cross-point buttons
• Utility 2 bus cross-point buttons
• DME external video bus cross-point buttons
• DME utility 1 bus cross-point buttons
• DME utility 2 bus cross-point buttons
• Memory recall buttons
h)
• Buttons set to “Inhibit”
• Auxiliary bus cross-point row
i)
Auxiliary bus control block
• Cross-point button1st row
b)
• Cross-point button 2nd row
b)
Keyframe control block • [RUN], [REWIND] and [FF] buttons
• [NORM], [REV], and [NORM/REV] buttons
Device control block (trackball,
joystick)
The buttons to which the same functions as those of
VTR/disk recorder/Extended VTR/frame memory
clips play, cue, stop, and start tc buttons
Device control block (search
dial)
[PLAY], [CUE], [STOP] and [START TC] buttons
Downstream key control block
• [DSK1 ON] to [DSK4 ON] buttons
a)
• [TAKE] button
a)
• [MIX], [WIPE], [DME], and [CUT] buttons
Transition control block
• [PTN LIMIT] button
c) d)
• [LIMIT SET] and [KF] buttons
c) d)
• [NORM], [NORM/REV], and [REV] buttons
c) e)
• [MIX], [NAM], [SUPER MIX], [PST COLOR MIX],
[WIPE], and [DME] buttons
• [MIX], [WIPE], and [DME] buttons
d)
• [ALL], [KEY PRIOR], [BKGD], and [KEY1] to
[KEY4] buttons
• [AUTO TRANS] button
a)
• [CUT] button
• [KEY1 ON] to [KEY4 ON] buttons
a)
Fade to black control block [FTB] button
Downstream key/fade to black
control block
• [DSK1 ON] and [DSK2 ON] buttons
a)
• [AUTO TRANS] button
a)
• [FTB] button
Utility/shotbox control block Memory recall buttons
Menu control block [PREFS 1] to [PREFS 16] buttons
