130 Parts List
2005995 Rev O – 210712
Other Replaceable Parts
Part Number Description Ink Base
2005900 CoPilot 500 Printhead - Oil-Based: Oil
2005901 CoPilot 500 Printhead - Solvent-Based Solvent
2005900-HS CoPilot 500 HiSpeed Printhead Oil
1602018 Photocell Assembly
1604177 Encoder Assembly Kit
2001065 Cartridge Ink System Porous Oil
2001066 Cartridge Ink System Non-Porous Solvent
2001079 CoPilot 500 Starter Kit, Oil Based, Cartridge Oil
2001080 CoPilot 500 Starter Kit, Solvent-Based, Cartridge Solvent
2001159 Bag Ink System Porous Oil
2001160 Bag Ink System Non-Porous Solvent
2002023 CoPilot 500 Starter Kit, Oil Based, Bag Oil
2002024 CoPilot 500 Starter Kit, Solvent-Based, Bag Solvent
2003585 Low Ink Alarm Beacon Assembly Kit Oil
2003588 Controller to Controller Data Cable 10ft.
2003864 RJ12 “Y” Splitter Cable
2003921 Printhead Data Cable 3ft.
2003927 Low Ink Alarm Beacon Assembly Kit Solvent
2004187 Power Supply Cord for Controller
2004918 Printhead Rotation/Tilt Mounting Kit
2004920 Mounting Bracket Assembly Oil
2005990
CoPilot 500 Controller
(works with CoPilot 500 Oil or Solvent Printhead)
2005095
CoPilot 500 Turbo Controller
(works with CoPilot 500 Oil or Solvent Printhead)
2005095-HS
CoPilot 500 Turbo Controller
(works with CoPilot 500 HiSpeed Printhead only)
Oil
