18 Introduction
2005995 Rev O – 210712
System Specifications
Print Technology Piezo impulse Printhead technology
Maximum Print Height 2.8” (7.1 cm) per Printhead
Maximum Throw Distance 0.19” (48.3 mm)
Message Length 180” (457.2 cm)
Vertical Print Resolution 185 dpi
Horizontal Print Resolution 205 dpi
Time and Date Internal real-time clock with battery backup
Product Sensor External Photocell trigger or optional Encoder
Communication Interface One USB host and one Ethernet input
Electrical Requirements 100–240 VAC, 50/60 Hz, 65 W maximum
Storage Environment 34 °F (1 °C) - 122 °F (50 °C)
Substrate Capabilities Porous and non-porous applications
Ink Capabilities Oil-based or solvent-based, depending on Printhead
Ink System
Passive Ink Control System:
Squid Ink Manufacturing 500 ml cartridge or 500 ml Bag Ink
systems.
Low Ink Indicator Message alert on Touchscreen
Optional Low Ink Alarm Beacon
Agency Certifications TUV and CE certified
