Installation and Setup 27
2005995 Rev O – 210712
Mounting
Each installation is unique, and Squid Ink Manufacturing cannot anticipate customer
requirements for attaching Mounting Brackets to the production line. Several mounting systems
are available for the CoPilot 500 printing system. Follow the instructions for the specific
mounting system ordered with your Printer.
ATTENTION: Use only the supplied Mounting Screws to attach the Printhead and
Controller to the Mounting Brackets. Using Mounting Screws other than those
supplied by Squid Ink Manufacturing can result in damage to the Printhead or the
Controller.
Main Components on Mounting Bracket
