Connecting to a Local Area Network
The network connection is located on the Controller. To connect to a local area network,
plug the Ethernet Cable into the Ethernet Port on the Controller and into the Ethernet Port
on a connected PC.
Local Area Network
Ethernet
Cable
Connecting to a Network
Ethernet
Port
Controller
