Squid Ink CoPilot 500 - Conveyor Mount Assemblies

132 Parts List
2005995 Rev O – 210712
Conveyor Mount Assemblies
Part Number Description
2004925
Tubing kit with one short Arm (14")
* Must order Printhead Mounting Post (2004918) to accommodate down,
horizontal, or twist applications
2004926
Tubing kit with two short Arms (14")
* Must order Printhead Mounting Post (2004918) to accommodate down,
horizontal, or twist applications
2004928 Tubing kit with Slider Brackets for two CoPilot 500 Printheads and Ink Systems
2004943
Tubing kit (single head) with black Printhead Plate for low profile Printhead
mounting
2004944
Tubing kit (dual head) with black Printhead Plates for low profile Printhead
mounting
2004950
Tubing kit with Slider Brackets for four CoPilot 500 Printheads and Ink Systems
and two Controllers
2005940
Mounting Bracket for complete printing system, includes:
• Mounting Bracket Assembly (2004920)
• Printhead Rotation/Tilt-Mounting Kit (2004918)
• Conveyor Mounting Assembly (2002059)
