24 Introduction
2005995 Rev O – 210712
Mounting Hardware
Squid Ink offers a variety of Floor Stands and Conveyor Mounts for a range of unique
situations (see “Replaceable Parts” on page 129). Floor Stand Mounts isolate the CoPilot
500 from vibrations and movements of the Conveyor. Conveyor Mounts attach directly to the
Conveyor. Contact your Squid Ink distributor for guidance on which stand best suits your
needs, and follow the mounting instructions for the mounting system that you choose.
NOTE: Stands and mounts do not come with CoPilot 500 Controllers or Printheads.
The “Floor Stand Assemblies” and “Conveyor Mount Assemblies” sections, starting on page
131, have complete lists of available Floor Stands and Conveyor Mounts.
Floor Stand
(Part Number 2004940)
Conveyor Mount
(Part Number 2004943)
