136 Parts List
2005995 Rev O – 210712
Item
Number
Part Number Description System Qty
2001065
Cartridge Ink System Assembly
Oil
2001066
Cartridge Ink System Assembly
Solvent
1
1603588
FTG-ELBOW, 1/8 BARB, #10-32
1
2
1705038
SCREW, M3 X 8, FH, BLK
18
3
2003069
PZP END PLATE
1
4
2003072
PZP INK SYS COVER
1
5
2003073
PZP INK SYSTEM BASE
1
6
2003074
PZP TANK COVER
1
7
2003099
PZP END PLATE W/CUT
1
8
2004129
FLOAT SWITCH, NC
1
9
2004131
CRIMP WIRE SPLICES 22-14 GA
2
10
2004156
CABLE, MOD-LOW INK, 6X4
1
11
2006025
FITTING, FEM LUER, CAP, PP
1
12
2006026
LUER LOCK RING USED W/2006027
1
13
2006027
FITTING-MALE LUER, 1/8 BARB
1
14
2006070
TIEWRAP 4” WITH #4 MTG HOLE
1
15
2006082
SCREW – FHP, M3 X 10MM, SS
8
16
2006083
SCREW – SHC, M6 X 10, SS
2
17
2006084
PZP TANK
1
18
2006085
O-RING, TANK, 70 DUR, BUNA
1
19
2006087
TEFLON BALL 5/32”
1
20
2006089
O-RING, SWITCH, 70 DUR, BUNA
1
21
2006091
SCREW, SHC, M3 X 20, SS
4
22
2006092
GROMMET RUBBER SBR 1/2 X 3/4
1
23
2006131
SPRING-COMP .3”ODx.69”Lx.025”
1
24
2006132
PLUG-BUTTON, 3/8”ID, .578D
1
25
2006133
FTG, BARBED, 1/4-28, 1/8 ID TUBE
1
26
2006134
FILTER-TUBE, 149 MICRON
1
27
2003379
TUBING LDPE 1/8” ID
Oil
1
1701002
TUBING LDPE 1/8” ID
Solvent
1
28
2007009
TUBING LDPE 1/8” ID
1
29
2007133
PZP COVER GASKET-GYLON
1
