142 Parts List
2005995 Rev O – 210712
Item
Number
Part Number Description Model Qty
2005095 Controller Standard
2005095-HS Controller HiSpeed
2005095 Controller Turbo
2005095-HS Controller HiSpeed Turbo
1 098898-001 LABEL-PROT EARTH GRND, IEC 5019 1
2 102448-001 NUT-KEP, M3, ZINC 1
3
1603530 ASSY-MAIN PCB*
Standard
HiSpeed
1
1440019 ASSY-MAIN PCB, COPILOT TURBO
Turbo
HiSpeed Turbo
1
4 1603526 GASKET – LCD SEAL, JETLINE & CP 1
5 1603529 AC-DC POWER SUPPLY, OUTPUT 24V 1
6 1603532 4.3” LCD W/ TOUCHSCREEN 1
N/S 1603548 CABLE ASSY – JUMPER FOR IEC LINE 1
N/S 1603575 BATTERY – 3V, 230mAh, COIN CELL 1
7 1603576 POWER SWITCH-ROCKER, 10A, 250 VAC 1
N/S 1603578 CABLE ASSY – JUMPER FOR IEC NEUT 1
N/S 1603601 FUSE – 4A, 5 X 20MM, FAST ACT 1
N/S 1603624 TAPE-2 SIDE ADHESIVE, 1/2” SQUARE 4
8 1605001 STANDOFF, HEX M/F, 3/16, ZINC* 4
9 2001430 SCREW – PHP, M3 X 6, W/EXT WASHER 8
10 2003907 FAB – CONTROLLER CHASSIS 1
11 2003908 FAB – BACK PLATE CONTROLLER 1
12 2003909 FAB – CONTROLLER COVER 1
13 2003912 PCB ASSY – HOST INTERFACE BOARD 1
N/S 2003917 CABLE ASSY – POWER TO MAIN PCB 1
N/S 2003918 CABLE ASSY – GROUND, FROM SWITCH 1
N/S 2003919 CABLE – PH DATA, RIBBON, 3.5” LONG 2
14 2003920
CABLE ASSY – POWER TO INTERFACE
BOARD
1
