Installation and Setup 33
2005995 Rev O – 210712
Bag Ink System
Items Needed to Mount a Bag Ink System:
• Alan Wrench
• Phillips Head Screwdriver
To Mount a Bag Ink System:
1. Use the supplied Screws to attach the side of the Ink Tray to the Ink System
Mounting Bracket.
Attaching the Ink Tray to the Mounting Bracket
Mounting
Bracket
Ink
Tray
