Objet1000 Plus User Guide 5 Using Objet Studio
DOC-06810 Rev.B 5-76
JobsQueue
Ontheserver,theJobs Queueliststhelast15jobssentfromclientcomputers.
Onclientworkstations,itlistsjobssentfromthatcomputertotheserver.
Informationforeachofthequeuedjobsisdisplayed,includingthejobstatus.
Status Meaning
Waiting Printingofthisjobhasnotstarted.
Building Printingofthisjobisinprogress.
Stopped Printingofthisjobwasinterrupted.Printingcanlaterbecontinued
(Resume)orbegunagain(Restart).
Error Errorsoccurredduringtheprintingofthisjob,anditwasplacedin
theJobsQueueagain.
Editing
ThisjobisnowbeingeditedinObjetStudio.
Spooling Thejobfileisbeingspooledintheprinter.
Preprocessing
The3Dprinterisreadyingitselfforprinting:thecoverlocks,
printheadswarmupandareputinstartingposition,UV
lampsareturnedon,andthebuildtraylevelisadjusted.
OnSchedule Thejobisscheduledtobeprintedataspecifiedtime.
Inaddition,thefollowinginformationisdisplayed:
•Owner—thecomputerthatsentthejob
•Build Time—theestimatedbuildingtimeforthejob
•ModelConsumption—theamountofmodelmaterialrequiredtocomplete
thejob,andtheamountactuallyusedtillnow
•SupportConsumption—theamountofsupportmaterialrequiredto
completethejob,andtheamountactuallyusedtillnow
•Printing Mode—HS=HighSpeed,HQ=HighQuality,DM=DigitalMaterial
Printing
Progress
TheTimepanelshowsprintingtimesandthenumberofslicessenttothe
printer.
History
TheHistorypanelshowsinformationforthelast50jobsandtheirfinal
status.YoucandragajobfromHistorytoJobs Queuetoprintthetrayagain.
Available
Resources
TheAvailable Resourcespanelcontainsgraphicindicatorsthatshowthe
amountofavailableprintingmaterialsremainingintheprinter.
1
Material
Consumption
•Actual—theamountofmaterialusedtillnow
•Required—theamountofmaterialstillneededtofinishthejob
TrayPreview
TheTray Preview paneldisplaysthebuildtrayviewofthejobselectedinthe
Job QueueortheHistorylist.
Onaserver,youcanopenanenlargedpreviewwindowbyclickingonthe
Tray Previewdisplay(see"AdditionalServerFeatures"onpage5-81).
Waste
TheamountofwasteappearswhenthecursorisovertheWaste display.
1
ObjetStudiodisplaystheweightoftheprintingmaterialsinbothcontainersaslongaseachcontainercontainsmorethan100gramsof
material.Theweightunder100gramsisnotcalculatedanddisplayed.However,ifacontainercontainslessthan100gramsofmaterial,
theprinterusesit—aslongasthematerialintheothercontainerweighsmorethan100grams.Inanycase,theweightofeachcontainer
isdisplayedintheprinterapplication.
